The Craftmade Inspo ceiling fan with its low profile, minimalist styling, multiple finishes, three speed reversible motor and included wall control is the inspired choice for any room.
Brand
Craftmade
Category
Indoor Ceiling Fans
Collection
Neighborhood Inspo
Finish
Various
Color
Blacks
Product Information
Brand:
Craftmade
Brand Category:
Ceiling Fan
Brand Product :
54″ Ceiling Fan w/Blades
Shipping Method:
Ground
SKU:
INS54FB3
UPC:
647881211509
Electrical and Operational Information
Efficiency:
95.5
Lamping Features:
Fixture Total Bulbs Included:
Lamping Included:
Bulbs Not Included
Lead Wire Length:
80.00
Voltage:
120
Dimensions and Measurements
Backplate/Canopy Extension:
2.21
Backplate/Canopy Height:
5.91
Backplate/Canopy Width:
5.91
Diameter:
54
Weight:
17.86
Width:
54
Fan Blade Information
Fan Blade Pitch:
14
Fan Blade Span:
54
Number of Fan Blades:
3
Fan Operational Information
Fan Features:
- Blade Status: Included / Blade Type: Fits Only / Reversible Blades: No / Blade Material: ABS / Blade Length: 23.524 / Blade Width: 6.378 / Blade Tip: Semi Square
- Motor Type: AC / Motor Speeds: 3 / Reverse Method: Slide Switch / Motor Diameter: 172 / Motor Height: 17 / Motor size combined: 172×17 / Motor Material: Silicon Steel
- Housing Size: 9.21 / Housing Height: 5.494
- Energy Guide CFM: 4342 / Energy Guide Watts: 41 / Energy Guide CFM Watts: 107 / FTC Test report Mean CFM High: 6647.73 / Energy Guide Est Yearly Energy Cost.: 11
- CFM High Max: 6682.38 / CFM Low Max: 1752.18
- CFM Watt High Max: 95.93
- Watt High Max: 69.97 / Watt Low Max: 7.01
- Amps High Max: 0.58
- RPM High Max: 146 / RPM Low Max: 46
- Light Kit Adaptable: No
- Control Status: Included / Control Types Included: CM-6W / Control features: Hard Wired Wall Control
- Reverse Location: Upper Housing
Motor Wattage:
69.97
Unit Air Flow:
6682.38
Included Components
Light Kit Included:
No
Warranty and Specifications
Country of Origin:
China
Install Position:
Dual Mount (Flat Or Angled Ceiling)
Prop 65:
Yes
UL Ratings:
cULus
Warranty:
Limited Lifetime Warranty
Additional Details
Chain Cord Features:
1x6in Downrod
Features:
- Crystal Components: No
- Not Light Kit AdaptableHard Wired Wall Control IncludedIndoor
- Room Size: Small rooms (up to 8 X 10)
- Slope Mount: Yes
- Downrod Diameter: 0.5
- Product Height (Primary Downrod): 13.21 / Blade to ceiling Height (Primary Downrod): 11.07
- Heavy-Duty, 3 Speed Reversible Motor
- Dual Mount (Flat or angled ceiling)
- 6″ Downrod (Included)
- Custom Blades Included
Material:
ABS/Steel/Silicon Steel
Switch Features:
Wall Control
